Building a Self-Hosted Raspberry Pi Server Cluster

When I decided to move away from expensive cloud hosting for my development projects, I knew I wanted something powerful, cost-effective, and fun to build. Enter the Raspberry Pi 5 cluster - a professional-grade server setup that delivers impressive performance while keeping costs reasonable.

Why Raspberry Pi 5 for Production?

The Pi 5 brought several game-changing improvements:

• 8GB RAM option: Finally enough memory for containerized applications
• PCIe support: Direct NVMe storage for dramatically better I/O
• Improved networking: Gigabit Ethernet with better throughput
• PoE+ support: Clean power delivery without individual adapters

Hardware Setup: Professional Rack Mounting

UCTRONICS Pi 5 Rack Mount System

The foundation of any serious Pi cluster is proper mounting. The UCTRONICS Pi 5 Rack Mount transforms four individual Pis into a clean, professional 1U server.

Key benefits:

• 1U standard rack size: Fits perfectly in server racks
• Excellent cooling: Built-in fans with temperature control
• Clean cable management: Organized power and network connections
• Easy access: Individual Pi modules slide out for maintenance

Power Over Ethernet with UCTRONICS PoE HAT

Rather than dealing with individual power supplies, I implemented PoE (Power over Ethernet) for clean, centralized power management.

"hl-comment"># Each Pi draws approximately 15W under load
"hl-comment"># PoE+ standard provides up to 25.5W per port
"hl-comment"># Perfect "hl-keyword">for Pi 5 + NVMe + PoE HAT overhead

The UCTRONICS Pi 5 PoE HAT provides:

• IEEE 802.3at PoE+ compliance: Reliable 25W power delivery
• Active cooling: Integrated fan with PWM control
• GPIO passthrough: Maintains access to all Pi 5 features
• Temperature monitoring: Automatic fan speed adjustment

Network Infrastructure: UniFi PoE Pro Max 16

For networking and PoE delivery, I chose the UniFi PoE Pro Max 16:

UniFi PoE Pro Max 16 Specifications:
- 16x Gigabit PoE+ ports (25.5W each)
- 400W total PoE budget
- Layer 2/3 switching capabilities
- VLAN support for network segmentation
- Remote power cycling per port

VLAN Configuration: I isolated the Pi cluster on a dedicated VLAN for security and management:

# VLAN Configuration
cluster_vlan:
  vlan_id: 100
  subnet: 192.168.100.0/24
  gateway: 192.168.100.1
  dns: 1.1.1.1, 1.0.0.1

# Pi assignments
pi_nodes:
  pi-01: 192.168.100.10
  pi-02: 192.168.100.11
  pi-03: 192.168.100.12
  pi-04: 192.168.100.13

This setup enables:

• Remote power cycling: Reset frozen nodes without physical access
• Network isolation: Cluster traffic separated from main network
• Centralized management: Single switch controls entire cluster
• Monitoring: Per-port power consumption tracking

Storage: NVMe Performance Boost

UCTRONICS NVMe Board Installation

The biggest performance bottleneck on previous Pi generations was storage. The Pi 5's PCIe support changes everything.

UCTRONICS NVMe Board benefits:

• M.2 2280 NVMe support: Full-size SSDs for maximum capacity
• PCIe Gen 2 interface: ~450MB/s throughput vs 50MB/s on SD cards
• HAT+ form factor: Stacks cleanly with PoE HAT
• No external power: Powered directly from Pi 5

Raspberry Pi Branded 512GB NVMe

I chose the official Raspberry Pi NVMe SSD (512GB) for each node:

"hl-comment"># Performance comparison
SD Card (Class 10):    ~50MB/s read/write
Official Pi NVMe:      ~450MB/s read/write
"hl-comment"># 9x performance improvement!

Why the official drive:

• Optimized firmware: Specifically tuned for Pi 5 PCIe implementation
• Thermal management: Designed for Pi thermal constraints
• Reliability: Rated for 24/7 operation
• Support: Full compatibility guarantee from Raspberry Pi Foundation

Operating System: Ubuntu Server Setup

Balena Etcher for NVMe Flashing

Setting up Ubuntu on NVMe requires a specific workflow:

"hl-comment"># 1. Download Ubuntu Server 24.04 LTS "hl-keyword">for Raspberry Pi
wget https://releases.ubuntu.com/24.04/ubuntu-24.04-preinstalled-server-arm64+raspi.img.xz
"hl-comment">
# 2. Flash to NVMe using Balena Etcher
"hl-comment"># - Connect NVMe via USB adapter
"hl-comment"># - Flash Ubuntu image to NVMe drive
"hl-comment"># - Do NOT boot Pi yet!

Pre-boot Configuration with user-data

Before first boot, I customize each Pi with cloud-init user-data:

# /boot/firmware/user-data
#cloud-config

# Basic system configuration
hostname: pi-cluster-01
timezone: Australia/Brisbane

# Users and SSH
users:
  - name: james
    groups: [adm, docker, sudo]
    shell: /bin/bash
    sudo: ['ALL=(ALL) NOPASSWD:ALL']
    ssh_authorized_keys:
      - ssh-ed25519 AAAAC3NzaC1lZDI1NTE5... # Your public key

# Packages to install
packages:
  - docker.io
  - docker-compose
  - htop
  - iotop
  - git
  - curl
  - ufw

# Docker configuration
runcmd:
  - systemctl enable docker
  - usermod -aG docker james
  - ufw --force enable
  - ufw allow ssh
  - ufw allow 80/tcp
  - ufw allow 443/tcp

# Network configuration for static IP
write_files:
  - path: /etc/netplan/99-cluster.yaml
    content: |
      network:
        version: 2
        ethernets:
          eth0:
            addresses: [192.168.100.10/24]
            gateway4: 192.168.100.1
            nameservers:
              addresses: [1.1.1.1, 1.0.0.1]

SSH Certificates for Secure Access

For enhanced security, I implement SSH certificates:

"hl-comment"># Generate CA key on management machine
ssh-keygen -t ed25519 -f ~/.ssh/cluster_ca -C "cluster-ca"
"hl-comment">
# Create host certificate "hl-keyword">for each Pi
ssh-keygen -s ~/.ssh/cluster_ca \
  -I pi-cluster-01 \
  -h \
  -n pi-cluster-01,192.168.100.10 \
  -V +52w \
  /etc/ssh/ssh_host_ed25519_key.pub
"hl-comment">
# Configure SSH daemon
echo "HostCertificate /etc/ssh/ssh_host_ed25519_key-cert.pub" >> /etc/ssh/sshd_config
echo "TrustedUserCAKeys /etc/ssh/cluster_ca.pub" >> /etc/ssh/sshd_config

Orchestration: Coolify Across 4 Nodes

Why Coolify Over Kubernetes?

While Kubernetes is powerful, it's overkill for small clusters. Coolify provides the perfect balance:

Coolify benefits:

• Simple setup: No complex YAML configurations
• Built-in reverse proxy: Automatic Traefik configuration
• SSL automation: Let's Encrypt integration
• Git deployment: Direct GitHub/GitLab integration
• Resource monitoring: Built-in metrics and alerting

Docker Swarm Cluster Setup

First, initialize the Docker Swarm cluster:

"hl-comment"># On pi-cluster-01 (manager node)
docker swarm init --advertise-addr 192.168.100.10
"hl-comment">
# Join other nodes as workers
"hl-comment"># Run this on pi-cluster-02, 03, 04
docker swarm join --token SWMTKN-... 192.168.100.10:2377
"hl-comment">
# Verify cluster
docker node ls

Coolify Installation

Install Coolify on the manager node:

"hl-comment"># Install Coolify
curl -fsSL https://cdn.coollabs.io/coolify/install.sh | bash
"hl-comment">
# Configure "hl-keyword">for multi-node
"hl-comment"># Coolify automatically detects Swarm nodes

Coolify Configuration:

# coolify.yml
version: '3.8'
services:
  coolify:
    image: coollabsio/coolify:latest
    ports:
      - '8000:80'
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
      - coolify_data:/data
    environment:
      - APP_URL=https://coolify.yourdomain.com
      - DB_PASSWORD=secure_password_here
    deploy:
      placement:
        constraints:
          - node.role == manager

Application Deployment Strategy

With Coolify, deploying applications becomes trivial:

"hl-comment"># Deploy a Next.js application
"hl-comment"># 1. Connect GitHub repository in Coolify UI
"hl-comment"># 2. Configure build settings:
"hl-comment">#    - Build command: npm run build
"hl-comment">#    - Start command: npm start
"hl-comment">#    - Port: 3000
"hl-comment"># 3. Set resource constraints per node
"hl-comment"># 4. Deploy with automatic SSL

Resource allocation strategy:

• pi-cluster-01: Coolify management + databases
• pi-cluster-02: Frontend applications (Next.js, React)
• pi-cluster-03: Backend APIs (Node.js, Python)
• pi-cluster-04: Services (Redis, monitoring tools)

Secure Internet Access: Cloudflare Tunnels

Why Cloudflare Tunnels?

Traditional port forwarding exposes your home IP and requires complex firewall rules. Cloudflare Tunnels provide a secure alternative:

Internet → Cloudflare Edge → Encrypted Tunnel → Your Pi Cluster

Benefits:

• No exposed ports: No inbound firewall rules needed
• DDoS protection: Cloudflare's global network shields your cluster
• Zero-trust security: Built-in access controls
• SSL termination: Automatic HTTPS for all services

Tunnel Setup

Install cloudflared on the manager node:

"hl-comment"># Install cloudflared
wget https://github.com/cloudflare/cloudflared/releases/latest/download/cloudflared-linux-arm64.deb
sudo dpkg -i cloudflared-linux-arm64.deb
"hl-comment">
# Authenticate with Cloudflare
cloudflared tunnel login
"hl-comment">
# Create tunnel
cloudflared tunnel create pi-cluster
"hl-comment">
# Configure tunnel
cat > ~/.cloudflared/config.yml << EOF
tunnel: pi-cluster
credentials-file: /home/james/.cloudflared/tunnel-credentials.json

ingress:
  - hostname: coolify.yourdomain.com
    service: http://192.168.100.10:8000
  - hostname: app1.yourdomain.com
    service: http://192.168.100.11:3000
  - hostname: api.yourdomain.com
    service: http://192.168.100.12:8080
  - service: http_status:404
EOF
"hl-comment">
# Start tunnel service
sudo cloudflared service install
sudo systemctl enable cloudflared
sudo systemctl start cloudflared

DNS Configuration

Configure your domain in Cloudflare:

"hl-comment"># Add CNAME records pointing to tunnel
coolify.yourdomain.com → tunnel-id.cfargotunnel.com
app1.yourdomain.com → tunnel-id.cfargotunnel.com
api.yourdomain.com → tunnel-id.cfargotunnel.com

Performance and Monitoring

Cluster Performance Metrics

After optimization, my 4-node cluster delivers:

Total Specifications:
- CPU: 16 cores (4x Cortex-A76 quad-core)
- RAM: 32GB (4x 8GB)
- Storage: 2TB NVMe (4x 512GB)
- Network: 4Gbps aggregate
- Power: ~60W total

Real-world performance:

• Web applications: Easily handles 1000+ concurrent users
• API responses: Sub-100ms response times
• Database operations: 10x faster than SD card setups
• Container startup: 3-5 seconds vs 30+ seconds on SD

Monitoring Stack

I use a lightweight monitoring setup:

# docker-compose.yml for monitoring
version: '3.8'
services:
  prometheus:
    image: prom/prometheus:latest
    ports:
      - '9090:9090'
    volumes:
      - ./prometheus.yml:/etc/prometheus/prometheus.yml
    deploy:
      placement:
        constraints:
          - node.labels.role == monitor

  grafana:
    image: grafana/grafana:latest
    ports:
      - '3001:3000'
    environment:
      - GF_SECURITY_ADMIN_PASSWORD=secure_password
    deploy:
      placement:
        constraints:
          - node.labels.role == monitor

Cost Analysis

Total Investment

Hardware Costs (AUD):
- 4x Raspberry Pi 5 (8GB): $120 × 4 = $480
- 4x UCTRONICS PoE HAT: $45 × 4 = $180
- 4x UCTRONICS NVMe Board: $35 × 4 = $140
- 4x Pi Official NVMe 512GB: $85 × 4 = $340
- UCTRONICS Rack Mount: $150
- UniFi PoE Pro Max 16: $650
- Miscellaneous cables: $50

Total Hardware: $1,990 AUD (~$1,300 USD)

Operating Costs

Monthly Costs:
- Power (60W × 24h × 30d × $0.25/kWh): $10.80
- Internet (included in home plan): $0
- Domain registration: $1.50
- Cloudflare Pro (optional): $20

Total Monthly: $32.30 AUD (~$21 USD)

ROI Comparison:

• Equivalent cloud resources: $200-300/month
• Break-even point: 6-7 months
• 5-year savings: $10,000+ AUD

Lessons Learned

What Works Great

1. PoE power management: Remote resets are invaluable
2. NVMe storage: Night and day performance difference
3. Coolify simplicity: Much easier than Kubernetes for small setups
4. Cloudflare Tunnels: Rock-solid security without complexity

Challenges Faced

1. Heat management: Ensure good airflow in rack enclosures
2. NVMe compatibility: Stick to officially supported drives
3. Network planning: VLAN setup requires careful planning
4. Initial complexity: Setup takes time but pays off long-term

Future Improvements

• Add load balancer: HAProxy for better traffic distribution
• Implement backup strategy: Automated backups to cloud storage
• Expand monitoring: More detailed application metrics
• Consider Pi 5 Compute Modules: Even more professional form factor

Conclusion

Building a Raspberry Pi 5 cluster has been incredibly rewarding. What started as a cost-saving exercise became a learning journey in modern DevOps practices. The combination of rack mounting, PoE, NVMe storage, and professional orchestration tools creates a surprisingly capable platform.

The Pi 5 represents a turning point where ARM-based mini computers become genuinely viable for serious computing tasks. Combined with modern tooling like Coolify and Cloudflare Tunnels, you can build enterprise-grade infrastructure on a hobbyist budget.

Whether you're a developer looking to reduce cloud costs, a student learning DevOps, or a hobbyist wanting to understand modern infrastructure, a Pi cluster project offers hands-on experience with real-world technologies.

Building your own Pi cluster? I'd love to hear about your setup! Connect with me on LinkedIn or check out more of my projects on my portfolio.
